Spring cage for the 3-plate clutch, compatible with your Puch moped equipped with a manual Z50 or EX30 (Z50) engine.
The spring cage is made of high-strength aluminum and features a hard coating. This reduces wear, which is particularly helpful for engines with increased power.
Inner Ø: 24.25 / 40.98 / 44.95 mm
Outer Ø: 49.85 / 62.00 / 53.58 mm
Height: 28.50 mm
Note: When installing, only a nut with a maximum height of 6 mm may be used for the M10x1 mounting nut. Additionally, the tension bolt must be readjusted.
You can find the appropriate tension bolt and other coupling parts in the accessories section.
| Manufacturer | ADR |
| Material | Aluminum |
| Color | bronze |
| Ø inside | 24.26 mm |
| Ø outside | 62 mm |
| Height | 27.5 mm |
| Number of teeth | 12 pcs |
| Puch | Z50 (X30 Sport) Z50 (X30 Velux) |
