Reproduction of the wide-wall cylinder with 50 cc displacement and narrow
| Manufacturer | AKOA |
| Material | Aluminum |
| Surface | varnished, Nickel silicon carbide (known as Nikasil®) |
| Displacement | 50 ccm |
| Crankshaft stroke | 44 mm |
| Ø piston pin (B) | 12 mm |
| Nominal diameter | 38 mm |
| Ø cylinder neck | 52 mm, 50.5 mm |
| Ø Outlet outside | 23 mm |
| Ø outlet inside | 19.5 mm, 11 mm |
| Inlet window | 18x7 mm |
| Thread inlet | M6x1 (standard thread) |
| Hole spacing outlet | 50.5 mm |
| Outlet type | slanted |
| Thread outlet | M6x1 (standard thread) |
| Decompressor | MF12x1.25 |
| Hole spacing inlet | 36 mm |
| Area of application | Standard |
| Pony OEM number | A2868 |
| Sachs | 503 - AB, AC, ADV |
