Oil seal NBR 15/35/7 A DUO crankshaft | Sachs 535

Loctite 243 medium-strength threadlocker 10 ml

Temperature resistance (min.): -75 - 200 °C · Color: blue · Manufacturer: Loctite · Material to be used: Aluminum · Material to be used: Metal · Material to be used: Steel · Contents [ml]: 10 ml · Hazard warning: Causes serious eye irritation · Hazard warning: Causes skin irritation · Hazard warning: Harmful to aquatic organisms (with long-term effects) · Hazard warning: May cause allergic skin reactions · Hazard warning: May irritate the respiratory tract · Signal word: Attention · Area of application: Chemistry · Hazard pictogram: GHS07 - Caution dangerous · Hazard pictogram: GHS09 - Hazardous to the aquatic environment · Adhesion: medium strength · Gap dimension (max.): 0.01 mm · Type of application: 1K · Alignment time: 600 sec · Breakaway torque (according to material): 3 N/m · Breakaway torque (according to material): 12 N/m · Breakaway torque (according to material): 26 N/m

Loctite 638 High-strength adhesive 10 ml

Manufacturer: Loctite · Material to be used: Aluminum · Material to be used: Metal · Material to be used: Steel · Area of application: Chemistry · Contents [ml]: 10 ml · Hazard warning: Causes serious eye damage · Hazard warning: Causes skin irritation · Hazard warning: Harmful to aquatic organisms (with long-term effects) · Hazard warning: May cause allergic skin reactions · Hazard warning: May irritate the respiratory tract · Color: green · Signal word: Danger · Hazard pictogram: GHS05 - Corrosive · Hazard pictogram: GHS07 - Caution dangerous · Adhesion: high-strength · Temperature resistance (min.): -75 - 150 °C · Gap dimension (max.): 0.25 mm · Type of application: 1K · Alignment time: 300 sec · Breakaway torque (according to material): 23 N/m · Breakaway torque (according to material): 25 N/m · Breakaway torque (according to material): 57 N/m

Oil seal NBR 15/32/5.5 A main shaft | Sachs 504, 505, 535 (A4216)

Temperature resistance (min.): -30 - 100 °C · Material: NBR · Surface: rubberized · Simmering type: A - With rubberized outer part / one sealing lip. · Width: 5.5 mm · Manufacturer: Sachs · Ø outside: 32 mm · Ø inside: 15 mm

Oil seal NBR 15/35/7 AS crankshaft | Sachs 504, 535 (A4214)

Temperature resistance (min.): -30 - 100 °C · Material: NBR · Surface: rubberized · Simmering type: AS - With rubberized outer casing / one sealing lip / one dust lip. · Width: 7 mm · Place of use: Crankshaft · Manufacturer: Sachs · Ø outside: 35 mm · Ø inside: 15 mm

Washer 30/36.8/1.5 crankshaft | Sachs 504, 535 (A4250)

Material: Steel · Surface: blank / oiled · Nominal diameter inside: 30 mm · Thickness: 1.5 mm · Manufacturer: Sachs · Ø outside: 36.8 mm · Ø inside: 30 mm

swiing® revival thrust washer 25.4/34/0.2 crankshaft | Sachs 504, 505, 508, 535 (A1678)

Material: Steel · Surface: hardened & ground · Thickness: 0.2 mm · Manufacturer: swiing® revival parts · Ø outside: 34 mm · Ø inside: 25.4 mm

Oil seal NBR 15/32/5.5 A main shaft | Sachs 504, 505, 535 (A4216)

Temperature resistance (min.): -30 - 100 °C · Material: NBR · Surface: rubberized · Simmering type: A - With rubberized outer part / one sealing lip. · Width: 5.5 mm · Manufacturer: Sachs · Ø outside: 32 mm · Ø inside: 15 mm

Oil seal NBR 15/30/5.5 A crankshaft | Sachs (A4215 & A5602)

Temperature resistance (min.): -30 - 100 °C · Simmering type: A - With rubberized outer part / one sealing lip. · Width: 5.5 mm · Place of use: Crankshaft · Manufacturer: Sachs · Material: NBR · Surface: rubberized · Ø inside: 15 mm · Ø outside: 30 mm · Pony OEM number: A5602 · Sachs OEM no.: 0230 111 100

NTN 6202 Ball bearing 15/35/11

Bearing type: Deep groove ball bearing · Bearing cage: "-" Sheet steel cage ball-guided · Stock number: 6202 · Width: 11 mm · Inner ring width: 11 mm · Manufacturer: NTN · Bearing clearance: CM (special/noise-reduced) · Groove ring: No · Material: Steel · Surface: blank · Ø inside: 15 mm · Ø outside: 35 mm · Ball bearing closed: No

NTN 6202 ball bearing 15/35/11 | Z50 motor

Bearing type: Deep groove ball bearing · Bearing cage: "-" Sheet steel cage ball-guided · Stock number: 6202 · Manufacturer: NTN · Bearing clearance: CN (standard) · Ø outside: 35 mm · Width: 11 mm · Ø inside: 15 mm · Puch OEM number: 900.4.6202

NTN 6202 Ball bearing 15/35/11 | Sachs 503 ADV/AB, 504, 535 (A1165)

Bearing type: Deep groove ball bearing · Bearing cage: "-" Sheet steel cage ball-guided · Stock number: 6202 · Width: 11 mm · Manufacturer: NTN · Bearing clearance: CN (standard) · Ø inside: 15 mm · Ø outside: 35 mm

Clutch cover gasket | Sachs 504, 505, 535 (A4278)

Material: Sealing paper · Manufacturer: Sachs · Number of fixing points: 5 pcs · Number of components: 1 pcs · Pony OEM number: A4278 · Sachs OEM no.: 0250 131 000

Gasket cylinder base Sachs 504, 505, 535 (A4277, A4456)

Place of use: Cylinder base · Manufacturer: Sachs · Pony OEM number: A4277 · Pony OEM number: A4456 · Sachs OEM no.: 0250 154 000

Cylinder base gasket Sachs 535 (A4425)

Place of use: Cylinder base · Manufacturer: Sachs

Oil seal FPM 15/30/5.5 AS

Temperature resistance (min.): -30 - 200 °C · Simmering type: AS - With rubberized outer casing / one sealing lip / one dust lip. · Width: 5.5 mm · Material: FPM - Fluororubber · Surface: rubberized · Ø inside: 15 mm · Ø outside: 30 mm

Oil seal FPM 15/30/5.5 AS crankshaft & main shaft | Sachs 503, 504, 505, 535 (A4215 / A5602)

Place of use: Crankshaft · Temperature resistance (min.): -30 - 200 °C · Simmering type: AS - With rubberized outer casing / one sealing lip / one dust lip. · Ø inside: 15 mm · Ø outside: 30 mm · Width: 5.5 mm · Manufacturer: Sachs · Material: FPM - Fluororubber · Surface: rubberized · Pony OEM number: A5602 · Sachs OEM no.: 0230 111 100
