Athena gasket set 45 mm AJH diaphragm

Athena 45 mm cylinder kit incl. diaphragm | Puch

Nominal diameter: 45 mm · Manufacturer: Athena · Material: Aluminum · Camouflaged: No · Area of application: Tuning · Surface: sandblasted · Displacement: 70 ccm · Crankshaft stroke: 43 mm · Ø cylinder neck: 47.8 mm · Ø outlet inside: 24 mm · Ø Inlet inside: 20.5 mm · Inlet window: 22 x 27.5 mm · Thread inlet: M5x0.8 (standard thread) · Hole pattern [mm]: 44 x 44 · Ø piston pin (B): 12 mm · Number of fixing points: 4 pcs · Outlet type: straight · Hole spacing outlet: 42 mm · Thread outlet: M6x1 (standard thread) · Decompressor: No · Hole spacing inlet: 31.5 mm

Parmakit 2-folding diaphragm insert carbon

Manufacturer: Parmakit · Number of flaps: 2 pcs · Membrane material: Carbon · Hole pattern [mm]: 60 x 40 mm · Mounting type: Screws · Number of fixing points: 4 pcs · Area of application: Tuning

Athena 45 mm cylinder kit incl. diaphragm AJH | Puch

Nominal diameter: 45 mm · Manufacturer: Athena · Material: Aluminum · Camouflaged: No · Area of application: Tuning · Surface: sandblasted · Displacement: 70 ccm · Crankshaft stroke: 43 mm · Ø cylinder neck: 47.8 mm · Ø outlet inside: 26 mm · Ø Inlet inside: 16 mm · Inlet window: 38 x 25 mm · Thread inlet: M6x1 (standard thread) · Hole pattern [mm]: 44 x 44 · Ø piston pin (B): 12 mm · Number of fixing points: 4 pcs · Outlet type: straight · Hole spacing outlet: 42 mm · Thread outlet: M6x1 (standard thread) · Decompressor: No · Hole spacing inlet: 40 mm · Hole spacing inlet: 60 mm

Athena gasket set 45 / 47 mm slot

Manufacturer: Athena · Area of application: Tuning · Number of components: 4 pcs · Ø cylinder: 45 mm · Ø cylinder: 47 mm · Hole spacing inlet: 38 mm · Hole spacing outlet: 42 mm · Hole pattern [mm]: 44 x 44 mm

2-folding membrane insert Athena AJH

Area of application: Tuning · Number of flaps: 2 pcs · Membrane material: Spring steel · Mounting type: Screws · Number of fixing points: 4 pcs · Hole pattern [mm]: 60 x 40 mm

Intake manifold Athena 45 mm Inox | Puch

Manufacturer: Made in Netherlands · Material: Chrome steel (colloquially known as stainless steel) · Area of application: Tuning · Ø inside: 21 mm · Mounting type: Screws · Number of fixing points: 4 pcs · Ø External connection: 24 mm

Elring Dirko HT sealing compound gray (silicone) 70 ml permanently elastic up to 315°C

Manufacturer: Elring · Area of application: Chemistry · Material: Silicone · Contents: 70 ml · Color: gray · Hazard warning: Causes damage to organs through prolonged or repeated exposure · Gap dimension (max.): 2 mm · Temperature resistance (min.): -60 - 315 °C

Elring Dirko HT sealing compound red (silicone) high temp. 70 ml elastic up to 315°C

Manufacturer: Elring · Color: red · Contents: 70 ml · Hazard warning: Causes serious eye irritation · Signal word: Attention · Hazard pictogram: GHS07 - Caution dangerous · Area of application: Chemistry · Gap dimension (max.): 2 mm · Temperature resistance (min.): -60 - 300 °C

GPO 45 mm cylinder head tuning new version | Puch (AT)

Material: Aluminum · Manufacturer: GPO · Ø cylinder: 45 mm · Height: 55 mm · Total length: 135 mm · Width: 140 mm · Number of fixing points: 4 pcs · Decompressor: No · Area of application: Tuning

swiing® revival stud bolt inlet/outlet M6 x 30 (10.9 strength)

Manufacturer: swiing® revival parts · Material: Steel · Diameter: 5.95 mm · Total length: 30 mm · Surface: galvanized (blue) · Nominal diameter (thread): 6 mm · Thread type: M6x1 (standard thread) · Thread length: 12 mm · Strength class: 10.9

Gas cable Ø 1.25 mm x 220 cm (cylindrical nipple) Bing

Ø nipple: 3 mm · Manufacturer: Made in Germany · Area of application: Standard · Material: Steel · Number of components: 1 pcs · Ø Stranded wire: 1.25 mm · Cable length: 2200 mm · Nipple shape: Cylinder · Surface: galvanized (blue) · Nipple length: 5 mm

Magura gas cable clamp / deco cable clamp Ø 5 x 6 mm

Manufacturer: Magura · Material: Brass · Material: Steel · Number of components: 2 pcs · Ø outside: 5 mm · Ø Cable bushing: 1.6 mm · Total length: 6 mm · Screw head: Lens head · Drive: Slot · Surface: nickel-plated · Thread type: M4x0.7 (standard thread) · Thread length: 4 mm

Motorex Automatic Motor Oil (ATF) 450 ml

Manufacturer: Motorex · Area of application: Gearbox lubrication with clutch · Contents: 450 ml · Gearbox type: Automatic machine · Temperature resistance (min.): -45 - 200 °C · Sachs OEM no.: 0263 014 002 · Pony OEM number: A2080

Intermediate flange cylinder Athena AJH Puch

Material: Plastic · Area of application: Tuning · Color: black-matt · Mounting type: Screws · Number of fixing points: 4 pcs · Hole pattern [mm]: 60 x 40

Athena 22 mm intake manifold Diaphragm Dell'Orto PHBG | Puch

Manufacturer: Athena · Area of application: Tuning · Material: Aluminum · Ø inside: 22 mm · Hole pattern [mm]: 60 x 40 · Mounting type: Screws · Number of fixing points: 4 pcs · Ø External connection: 26 mm

DMP 45 mm cylinder kit incl. diaphragm | Puch

Nominal diameter: 45 mm · Manufacturer: DMP · Material: Aluminum · Surface: sandblasted · Displacement: 70 ccm · Crankshaft stroke: 43 mm · Number of fixing points: 4 pcs · Ø piston pin (B): 12 mm · Hole pattern [mm]: 44 x 44 · Hole spacing outlet: 42 mm · Thread outlet: M6x1 (standard thread) · Camouflaged: No · Area of application: Tuning

Athena diaphragm seal AJH

Manufacturer: Athena · Material: Oiled paper · Area of application: Tuning · Place of use: Admission · Thickness: 0.5 mm · Hole pattern [mm]: 40 x 62 · Ø screw holder: 6.7 mm

swiing® revival gasket gearbox cover engine 1 mm | Puch E50

Manufacturer: swiing® revival parts · Material: Sealing paper · Color: sand-colored · Number of components: 1 pcs · Ø outside: 116 mm · Thickness: 1 mm · Ø inside: 106 mm · Number of fixing points: 4 pcs · Alternative version of the Puch OEM number: 349.1.10.349.1
